CARMIX 3.5 TT selfloading concrete mixer
for an effective capacity of 3,5m per batch.
For an easy discharge over all sides of the machine at up to 2m height, the drum is slewing by 300 .
Characteristics CARMIX 3.5TT
Drum Capacity 4.850 Liter
Concrete per batch 3,5m
300 Drum rotation for an easy discharge
Productivity: 4 batches per hour
Engine: Diesel PERKINS 1104 D-44 TA
Operators Cabin: Frontcabin on loading side. ROPS FOPS Cabin complete with double door.
Water: Watertank on board, alternatively water can be pumped from an external source.
Loading Bucket : Capacity 600 l , complete with hydraulic discharge.
climbing ability: fully loaded 30%.
electronic weighing system (optional):
Load cells continously weigh the drum
precise control of the aggregates loaded
store up to 40 concrete recepies
Documentation of the batch by a printale weighing ticket
A homologization as a selfpropelled working machine is possible.
